Технические характеристики
|
Номинальный диаметр троса (мм) |
D1 |
D2 |
D3 |
D4 |
H1 |
H2 |
H3 |
H4 |
b |
L |
E |
t |
t1 |
t2 |
R |
|
150 |
165.2 |
185 |
- |
80 |
330 |
90 |
70 |
60 |
155 |
400 |
- |
8.0 |
6 |
6 |
40 |
|
200 |
216.3 |
240 |
- |
130 |
395 |
115 |
70 |
60 |
205 |
500 |
- |
8.0 |
6 |
6 |
50 |
|
250A |
267.4 |
290 |
- |
160 |
505 |
135 |
90 |
75 |
250 |
630 |
- |
12.0 |
9 |
8 |
60 |
|
250B |
267.4 |
290 |
- |
160 |
505 |
135 |
90 |
75 |
250 |
630 |
- |
10.0 |
8 |
7 |
60 |
|
300A |
318.5 |
340 |
150 |
185 |
600 |
150 |
110 |
85 |
290 |
800 |
300 |
21.5 |
16 |
9 |
70 |
|
300B |
318.5 |
340 |
150 |
185 |
600 |
150 |
110 |
85 |
290 |
800 |
300 |
12.0 |
9 |
9 |
70 |
|
350A |
355.6 |
380 |
170 |
200 |
685 |
175 |
130 |
105 |
340 |
890 |
350 |
26.0 |
19 |
11 |
80 |
|
350B |
355.6 |
380 |
170 |
220 |
685 |
175 |
130 |
105 |
340 |
890 |
350 |
14.0 |
10 |
9 |
80 |
|
400A |
406.4 |
430 |
190 |
230 |
730 |
185 |
145 |
115 |
380 |
1000 |
380 |
28.0 |
20 |
13 |
85 |
|
400B |
406.4 |
430 |
190 |
250 |
730 |
185 |
145 |
115 |
380 |
1000 |
380 |
15.0 |
11 |
11 |
85 |
|
450A |
457.2 |
480 |
210 |
265 |
770 |
195 |
160 |
120 |
425 |
1100 |
410 |
29.0 |
21 |
14 |
90 |
|
450B |
457.2 |
480 |
210 |
285 |
770 |
195 |
160 |
120 |
425 |
1100 |
410 |
14.5 |
11 |
11 |
90 |
|
500A |
508.0 |
530 |
235 |
295 |
830 |
230 |
200 |
150 |
480 |
1250 |
460 |
32.0 |
23 |
16 |
100 |
|
500B |
508.0 |
530 |
235 |
320 |
830 |
230 |
200 |
150 |
480 |
1250 |
460 |
14.5 |
11 |
11 |
100 |
|
550A |
558.8 |
580 |
255 |
330 |
900 |
270 |
200 |
180 |
520 |
1380 |
540 |
31.0 |
22 |
16 |
110 |
|
550B |
558.8 |
580 |
255 |
350 |
900 |
270 |
200 |
180 |
520 |
1380 |
540 |
21.0 |
16 |
11 |
110 |
|
600 |
609.4 |
630 |
280 |
365 |
950 |
300 |
200 |
200 |
560 |
1550 |
600 |
33.0 |
23 |
16 |
120 |
|
Номинальный диаметр троса |
Сварная лапа |
Допустимая нагрузка |
Вес |
||||||
|
Для швартовки |
Для буксировки |
||||||||
|
мм |
z1 |
z2 |
1 трос |
2 троса |
(кг) |
||||
|
(КН) |
(t) |
(КН) |
(t) |
(КН) |
(t) |
||||
|
150 |
3.5 |
3.5 |
54 |
5.5 |
49 |
5.0 |
383 |
10 |
29 |
|
200 |
3.5 |
3.5 |
82 |
8.4 |
65 |
6.7 |
579 |
13 |
46 |
|
250A |
5.5 |
4 |
156 |
16 |
134 |
14 |
1315 |
27 |
107 |
|
250B |
5.5 |
4 |
127 |
13 |
108 |
11 |
215 |
22 |
91 |
|
300A |
10.5 |
4 |
332 |
34 |
306 |
31 |
3365 |
62 |
281 |
|
300B |
10.5 |
4 |
186 |
19 |
161 |
16 |
352 |
36 |
166 |
|
350A |
12.5 |
5 |
443 |
45 |
418 |
43 |
5062 |
85 |
431 |
|
350B |
7 |
4 |
244 |
25 |
216 |
22 |
2855 |
50 |
241 |
|
400A |
12.5 |
6 |
594 |
61 |
521 |
53 |
6632 |
106 |
570 |
|
400B |
8 |
5 |
326 |
33 |
269 |
27 |
3816 |
67 |
322 |
|
450A |
12 |
7 |
753 |
77 |
612 |
62 |
8201 |
124 |
712 |
|
450B |
8 |
7 |
382 |
39 |
292 |
30 |
4483 |
78 |
379 |
|
500A |
12.5 |
8 |
992 |
101 |
757 |
77 |
10928 |
154 |
960 |
|
500B |
8 |
5 |
457 |
47 |
326 |
33 |
5474 |
93 |
465 |
|
550A |
11.5 |
8 |
1131 |
115 |
812 |
83 |
12635 |
165 |
1123 |
|
550B |
11.5 |
5 |
781 |
80 |
541 |
55 |
9280 |
159 |
787 |
|
600 |
11.5 |
8 |
1401 |
143 |
948 |
97 |
15539 |
193 |
1391 |
